Természetesen csöves phono elektronika. Összesen 4 db csövet tartalmaz (3db 12AX7 + 1db 12AT7). MC bemeneti impedanciája 150 Ohm, kimeneti 400 Ohm. MM/MC átváltás belső jumperrel.
| MC | MM | ||||
|---|---|---|---|---|---|
| Vacuum Tube Complement | 1 x 12AU7 | 2 x 12AX7, 1 x 12AT7 | |||
| Inputs | 1 pair single-ended RCA | 1 pair single-ended RCA | |||
| Outputs | 1 pair single-ended RCA | ||||
| Gain (Total 62dB) | 56 dB or 62 dB | 42 dB | |||
| Output Impedance | 425Ω | ||||
| Frequency Response +0 -1 dB | 10Hz – 50kHz | ||||
| Maximum Output Voltage <1% THD | 20V | ||||
| Cartridge load impedance | Variable: 100Ω, 250Ω, 470Ω, 1kΩ, 4k7Ω, 47kΩ | 47kΩ, 100kΩ | |||
| Minimum Recommended Cartridge Output | 0.2 mV | 1.5 mV | |||
| Signal to Noise Ratio | 50 dB | 56 dB | |||
| Channel Separation | > 50dB (20 Hz – 20 kHz) | ||||
| Power Consumption | 25W | ||||
| Dimensions W x D x H | 19 x 14 x 3.75″ / 48.25 x 35.5 x 9.5 cm | ||||
| Weight | 25 lbs (11.34 kg) packed | ||||
