Vacuum Tube Complement | 8 x 6550 or KT-88, 2 x 12AT7, 2 x 12BH7 |
Output power 20Hz – 20kHz <2.5% THD |
Tetrode: 200W, Triode: 100W into 5Ω load |
Input sensitivity | Variable between 700mV and 1.6V, depending upon DF setting |
Input impedance | 45kΩ |
Load setting | 5Ω |
Optimum load range | 4Ω – 8Ω |
S/N Ratio | -110dB, 120 Hz |
Power consumption | Idle = 330W, Full power = 1000W |
Primary mains fuse ratings | 100/120V = 15A Ceramic Slo Blo, 220/240V = 8A Ceramic Slo Blo |
Input fuse ratings | 100/120V = 1A Ceramic Slo Blo, 220/240V = 1A Ceramic Slo Blo |
Logic fuse | 100/120V = 1A Ceramic Slo Blo, 220/240V = 1A Ceramic Slo Blo |
B+ fuse ratings | Plate Fuse – 1.0A fast acting 600V |
Dimensions W x D x H | 18.5 x 18 x 9 inches (47 x 45.7 x 23 cm) |
Weight | 105lbs (47.6Kg) unpacked, 120lbs (54Kg) packed |
