ML-80i

ML-67i

ML-66i

ML-65i

ML-62i

ML-60i

Frequency Response

60–20,000 Hz ±2dB

70–20,000 Hz ±2dB

75–20,000 Hz ±3dB

70–20,000 Hz ±3dB

70–20,000 Hz ±3dB

70–20,000 Hz ±3dB

Aiming

—

Rotate speaker assembly

—

—

Rotate speaker assembly

—

Sensitivity

90 dB/2.83 volts/meter

89 dB/2.83 volts/meter

89 dB/2.83 volts/meter

89 dB/2.83 volts/meter

89 dB/2.83 volts/meter

89 dB/2.83 volts/meter

Nominal Impedance

8 Ohms. Compatible with 4, 6 or 8 ohm rated amplifiers.

8 Ohms. Compatible with 4, 6 or 8 ohm rated amplifiers.

8 Ohms. Compatible with 4, 6 or 8 ohm rated amplifiers.

8 Ohms. Compatible with 4, 6 or 8 ohm rated amplifiers.

8 Ohms per channel/connection. Compatible with 4, 6 or 8 ohm rated amplifiers.

8 Ohms. Compatible with 4, 6 or 8 ohm rated amplifiers.

Recommended Amplifier Power

15-120 watts per channel

15-100 watts per channel

15-140 watts per channel

15-120 watts per channel

15-80 watts per channel

15-100 watts per channel

Crossover Frequency

2500 Hz

2500 Hz

2500 Hz

2500 Hz

3000 Hz

3000 Hz

High Frequency Transducer

1" (2.5cm) titanium dome

1" (2.5cm) titanium dome

3/4" (2.5cm) titanium dome

3/4" (2.5cm) titanium dome

Two 3/4” (1.9cm) titanium domes

3/4” (1.9cm) titanium dome

Low Frequency Driver

8" (21cm) mineral-filled polypropylene cone

6.5" (16.5cm) mineral-filled polypropylene cone

Two 5.5” (14cm) mineral-filled polypropylene cones

6.5” (16.5cm) mineral-filled polypropylene cone

Dual voice-coil 6.5” (16.5cm) mineral-filled poly cone

6.5” (16.5cm) mineral-filled polypropylene cone

Inputs

Spring clip accommodates wire up to 12AWG

Spring clip accommodates wire up to 12AWG

Spring clip accommodates wire up to 12AWG

Spring clip accommodates wire up to 12AWG

Spring clip accommodates wire up to 12AWG

Spring clip accommodates wire up to 12AWG

Weight

4.4 lbs. (2 kg) each

5.3 lbs. (2.4 kg) each

5.9 lbs. (2.7 kg) each

3.5 lbs. (1.6 kg) each

3.5 lbs. (1.6 kg) each

3.5 lbs. (1.6 kg) each

Overall Dimensions
(DiameterxD | HxWxD)

10.5 x 4 inches
(26.6cm x 10cm)

11.4 x 5.4 inches
(29cm x 13.5cm)

9.3 x 12.7 x 3.4 inches
(23.7cm x 32.3cm x 8.6cm)

11.5 x 8.3 x 3.3 inches
(29.1cm x 21.2cm x 8.5cm)

8.8 x 3.6 inches
(22.4cm x 9cm)

8.8 x 3.4 inches
(22.4cm x 8.5cm)

Required Opening
(Diameter | HxWxD)

9.375 inches (23.8cm)

10.375 inches (26.3cm)

8.25 x 11.625 inches
(20.9cm x 29.5cm)

7.125 x 10.125 inches
(18cm x 25.7cm)

7.75 inches (19.6cm)

7.75 inches (19.6cm)

Projection From Wall Surface

0.2 inches (0.5cm)

0.2 inches (0.5cm)

0.2 inches (0.5cm)

0.2 inches (0.5cm)

0.2 inches (0.5cm)

0.2 inches (0.5cm)

Depth Required Behind Wall Surface

3.8 inches (9.5cm)

5.2 inches (13cm)

3.2 inches (8.1cm)

3.1 inches (7.9cm)

3.4 inches (8.5cm)

3.2 inches (8cm)

ML-75AW

ML-65AW

ML-55AW

ML-45AW

Frequency Response

75–20,000 Hz ±2dB

80–20,000 Hz ±2dB

85–20,000 Hz ±2dB

90–20,000 Hz ±2dB

Aiming

Swivels on U-Bracket

Swivels on U-Bracket

Swivels on U-Bracket

—

Sensitivity

93 dB

91 dB

90 dB

88 dB

Nominal Impedance

8 Ohms. Compatible with 4, 6 or 8 ohm rated amplifiers.

8 Ohms. Compatible with 4, 6 or 8 ohm rated amplifiers.

8 Ohms. Compatible with 4, 6 or 8 ohm rated amplifiers.

8 Ohms. Compatible with 4, 6 or 8 ohm rated amplifiers.

Recommended Amplifier Power

15-160 watts per channel

15-140 watts per channel

15-120 watts per channel

15-100 watts per channel

Crossover Frequency

2300 Hz

2300 Hz

2300 Hz

2300 Hz

High Frequency Transducer

1" (2.5cm) titanium dome

1" (2.5cm) titanium dome

1" (2.5cm) titanium dome

1" (2.5cm) titanium dome

Low Frequency Driver

7.5” (19cm) mineral- filled polypropylene cone

6.5” (16.5cm) mineral- filled polypropylene cone

5.5” (14cm) mineral- filled polypropylene cone

4.5” (11.5cm) mineral- filled polypropylene cone

Inputs

5-way binding posts accommodate wire up to 5AWG

5-way binding posts accommodate wire up to 5AWG

5-way binding posts accommodate wire up to 5AWG

5-way binding posts accommodate wire up to 5AWG

Weight

10.6lbs. (4.8kg) each

8.8lbs. (4kg) each

6.75lbs. (3.05kg) each

3.4lbs. (1.55kg) each

Overall Dimensions
(HxWxD)

12.5 x 8.81 x 9.13 inches
(31.7cm x 22.4cm x 23.2cm)

11 x 7.5 x 7.94 inches
(28cm x 19cm x 20.2cm)

9.69 x 7 x 7.63 inches
(24.6cm x 17.8cm x 19.4cm)

7.56 x 5.63 x 5.94 inches
(19.2cm x 14.3cm x 15.1cm)

ML-75R

ML-65R

Frequency Response

63–20,000 Hz ±2dB

66–20,000 Hz ±2dB

Sensitivity

90 dB/2.83 volts/meter

89 dB/2.83 volts/meter

Nominal Impedance

8 Ohms per channel/connection. Compatible with 4, 6 or 8 ohm rated amplifiers.

8 Ohms per channel/connection. Compatible with 4, 6 or 8 ohm rated amplifiers.

Recommended Amplifier Power

15-80 watts per channel

15-70 watts per channel

Crossover Frequency

2500 Hz

3000 Hz

High Frequency Transducer

Two 1" (2.5cm) titanium dome

Two 1" (2.5cm) titanium dome

Low Frequency Driver

7.5" (19cm) mineral-filled polypropylene cone with dual voice coil.

6.5" (16.5cm) mineralfilled polypropylene cone with dual voice coil.

Inputs

Two pair pre-installed wires

Two pair pre-installed wires

Weight

17lbs. (7.7kg) each

12.1lbs. (5.5kg) each

Overall Dimensions
(HxWxD)

15.1875 x 13.375 x 13 inches
(38.5cm x 34cm x 33cm)

12.1875 x 11.125 x 10.625 inches
(31cm x 28.2cm x 27cm)
